What do I need to prepare to install a dumbwaiter in Malaysia?

You need three basic items: shaft space of 1000mm x 1000mm, clear vertical space between floors with no obstruction, and a power supply with isolator (3-phase 415Vac, 20 Amp). A site visit helps confirm if unsure.

How is the dumbwaiter installation process?

We carry out a site visit and take measurements. Upon receiving the deposit, we fabricate the dumbwaiter, install the system, test it, and hand over ready to use.

How long does dumbwaiter installation take?

Manufacturing usually takes 2-3 weeks. On-site installation takes only 2-3 days, including testing and commissioning.

What materials can be used to cover the dumbwaiter shaft?

Common shaft cover options include PU panel, cement board, and expanded metal. Custom materials or designs can also be reviewed on request.

What warranty and maintenance are provided?

We provide a 5 year warranty for the motor and a 2 year warranty for manufacturing defects. Servicing is recommended once every 4-6 months, with urgent breakdown service available.

Can the dumbwaiter carry more than 100kg or be custom sized?

Yes. Methodcon can design dumbwaiters with higher load capacity and custom lift sizes based on your requirements.

WhatsApp Chat

FOOD LIFT / DUMBWAITER (100KG MAX Weight)

In Malaysia, ground floor shop space can cost up to 50% more than the floor just above it. For example, one building in KL rents its ground floor at RM9,000/month, while the first floor above is only RM6,000/month.

With a dumbwaiter, you can move your kitchen, storage, or prep area to the cheaper upper floor — and still serve food fast. It only takes about 7.5 seconds to send food between floors.

Methodcon Dumbwaiter makes this easy to achieve.

Chat with us to arrange a free consultation and site visit. - Click here

2X your SEATING space

Expand your café, restaurant, or central kitchen upstairs at a fraction of renovation cost — our lift only needs 1000mm × 1000mm space, about the size of a small table.

100kg Load Capacity

Sized at 700mm (W) × 600mm (D) × 900mm (H). That’s more than 20 large pizza boxes stacked inside.

3-Day Installation

Minimal downtime — your kitchen and service can run as usual while we set up the lift, keeping operations smooth and uninterrupted.

TECHNICAL SPECIFICATIONS - DUMBWAITER / FOOD LIFTS 100kg

Methodcon 100kg dumbwaiter lift is simple and straightforward — no complicated planning needed. We manufacture and install everything for you, including the shaft and wall covering, so there's no need to build a separate structure beforehand. From start to finish, we handle it all and hand it over ready to use.




    Type: Methodcon 100kg Dumbwaiter


    Basic Specifications

Load Capacity100 kg
Speed0.4 m/s
Service FloorsUp to 4 floors
Door ConfigurationMultiple door options available
Main Power Supply3-Phase, 415V, 50Hz
Lighting Power Supply3-Phase, 220V, 50Hz (or as required)

    Control System

Control TypeProgrammable Logic Control (PLC)

    Mechanism

Drive SystemTraction motor
Machine RoomInside lift shaft / hoistway overhead
Pit DepthNot required

    Car Specifications

Car Size (W×D×H)700 × 600 × 900 mm
Door Opening TypeUp opening
Door Size (W×H)700 × 900 mm
Car Wall Finishing304 Stainless steel, hairline finish
Ceiling & Lighting304 Stainless steel, hairline finish, LED lighting
Flooring304 Stainless steel, hairline finish
Trays3 removable, kitchen-grade stainless steel

    Controls & Communication

Push ButtonsLift-style push buttons with floor indicator
IntercomIncluded at each door / floor

    Landing Door

Main Landing Door Finish304 Stainless steel, hairline finish
Typical Floor Door Finish304 Stainless steel, hairline finish
Door JambsNarrow jamb, hairline stainless steel finish

    Shaft Wall Covering Options

Available FinishesPU Panel, Cement Board, Brick Wall, Expanded Metal

    Installation Service

Lift Shaft / Hoistway ConstructionOptional — available on request
Handover ConditionFully installed, tested & ready to use — A to Z service




To install a dumbwaiter, you only need three basic items:
- Shaft space of 1000 mm × 1000 mm
- Clear vertical space between floors with no obstruction
- Power supply with isolator: 3-phase 415Vac, 20 Amp
If you are unsure, a site visit helps confirm whether the space is suitable. Contact us on Whatsapp.
The installation process is straightforward.
We carry out a site visit, take measurements. Upon receiving the deposit, we will fabricate the dumbwaiter, install the system, test it, and hand over.
After installation, the dumbwaiter is ready to use.
Manufacturing usually takes 2–3 weeks.
On-site installation takes only 2–3 days, including testing and commissioning.
Common shaft cover options include:
- PU panel
- Cement board
- Expanded metal
If you have a different design or material in mind, we can review and advise. Contact us on Whatsapp!
- 5 years warranty for the motor
- 2 years warranty for manufacturing defects
We recommend servicing once every 4–6 months to keep the dumbwaiter running smoothly and safe.
Urgent breakdown service is available when required.
Yes. We can design dumbwaiters with higher load capacity and custom lift sizes based on your needs.

📲 Contact us via WhatsApp to discuss your requirement.

Frequently Asked Questions

Ready to fit a dumbwaiter into your RESTAURANT?

Your lift arrives fully set up and ready to use — no extra work needed on your end. We also provide preventive maintenance, on-call breakdown service, and extended warranty options to keep it running long after installation.

Ready to fit a dumbwaiter into your kitchen? Chat with us on WhatsApp for a free consultation and site visit.
